Specifications
Product Description
UHD
Display Technology
D-LED
Front Cabinet
Plastic, Black
Chipset solution
AN.M9612-UT
Back Cover Color
Plastic, Black
Base Stands
“Bridge” shape, Metal, Black
UNIT (with stand)mm
1452.1*898.8*293.1
UNIT (without stand)mm
1452.1*834.6*89.5
Carton Dimension (W*D*H) mm
1623*181*974
Net weight/Gross weight（KG）
17.8/23.7
Wall Support Type
400*200
Aspect ratio
16:9
Resolution
3840*2160
Refresh Rate
60Hz
Brightness(Type:cd/m2)
330nit
Contrast Ratio (Typical)
5000:1
Viewing Angle( L/R/)
170/170
Response Time(Tr+Tf /typ.) (ms)
6.5
Display colors
1.07G (8-bit+FRC)
Side
1*RF, 2*USB, 1*EARPHONE,
1*LAN, 1*OPTICAL, 4*HDMI, 1*AV
Bottom
/
OS
Officail Android 11
CPU
CA55*4
GPU
G52*2
DDR SIZE
2GB
Flash
16GB
Bluetooth
Bluetooth2.1+EDR/4.2/5.0
WIFI
IEEE 802.11 ac/b/g/n, 2T2R, 2.4G+5.0G
Reception Range
48.25MHz ~ 863.25MHz
Input impedance
75Ω
Video System
PAL, SECAM
Sound System
BG、I、DK、L
Max Storage Channels
100CH
TV digital System
DVB-T/T2/C/S2
Reception Range
DVB-T/T2: VHF (174MHz ~ 230MHz)
UHF (474MHz ~ 862MHz)
DVB-S/S2: (950Mhz-2150MHz)”
Channel Bandwidth
6MHz/ 7MHz/8MHz
Input impedance
75Ω
Max Storage Channels
DVB-T/DVB-T2:9999
DVB-C:1000
DVB-S2:9999
Picture Mode
User/Standard/Vivid/Sports/Movie/ Game/Energy saving
Dynamic backlight
No
MEMC
Yes
3D Comb Filter
Yes
Dynamic Noise Reduction
Yes
Local Diming
No
HDR
YES (DOLBY VISION)
Wide Color Gamut
No
Speaker Position
Integrated speakers (Bottom side)
Subwoofer
No
Balance
Yes
STEREO
Yes
Sound Mode
User/Standard/Vivid/Sports/Movie/ Music/News/Auto
Dolby/Dolby+
Yes
DOLBY ATMOS
Yes
Surround
Yes
OSD Language
English/Russian/Ukrainian…
Open Broswer
No
App Store
Google Play
Multiscreen(Miracast)
Yes
Pre-Install Application
Netflix,Amazon Prime Video,
LiveTV, YouTube, Google Play Movies & TV,
Google Play Store, Media, Google Play Game, etc.
Software upgrading
USB and Internet
EPG
Yes
Subtitle
Yes
Teletext
Yes
Sleep Timer
Yes
Parental Lock
Yes
Hotel Mode
No
Light Sensor
No
Color Temperature
Warm/Cold/Standard /User
ARC
Yes
MHL
No
CEC
Yes
Video Decoder
HEVC/MPEG2/MPEG4/
H264/VC1/VP8/VP9/FLV/AV1
Audio Decoder
MPEG2/DD/DD+/AAC/Dolby Atmos/DBX
Photo Decoder
JPG/JPEG/BMP/PNG
Speaker Output Power (W)
2*10
Power Supply
100V~240V,50/60Hz
Rated Power (W)
180
Standby Mode Consumption (W)
≤0.5
Remote Control
IR&BT RC
