2008020000003
FRANZI 500
The first folding e-bike from Blaupunkt, which has a specially adapted front motor. The advantage of the front engine is the additional coaster brake, with which you can brake easily and safely.
Intelligent clamping mechanism!
Equipped with an intelligent clamping mechanism, the Blaupunkt Franzi 500 can be easily folded and thus reduced in size by half. In just 4 steps, the folding e-bike becomes a handy and easy-to-stow “package”. The low weight of approx. 22 kg also makes it easy and comfortable to take with you on the bus and train.
Strong engine!
The strong 36-volt front-wheel motor with 50 Nm provides the perfect support, which together with the removable and powerful lithium-ion battery forms a perfect team. The motor is durable and to protect the battery, the integrated BMS (Battery Management System) always ensures an optimal energy supply.
LCD bike computer!
The 5 levels of the motor are controlled via the easy-to-read LCD computer. It also provides important information such as the current battery life, information about the route, speed and much more. The engine power can also be completely deactivated.
Folding eBike Franzi 500
The first folding e-bike from Blaupunkt, which has a specially adapted front motor. The advantage of the front engine is the additional coaster brake, with which you can brake easily and safely.
approx. 22 kg weight (incl. battery)
up to 80 km* range
*The range depends on the load, driving style and area of use.
Specifications
Highlights
• 20“ low step through E-Bike with particularlylow entry
• Front hub motor with optimized controller
• Elegant titanium- matt finish with contrastingelements (tires, handles & saddle)
• Suspension seat post
• 3 brakes (V- brakes + coaster brake)
• Brake light
• Shimano 3-speed hub shifter/ ShimanoRevo- Shift
• Stable, foldable aluminum frame
• Easily stowed thanks to intelligent quick- foldingmechanism including foldable pedals &handlebar
• Comfortable 20” x 2.125 tires
• Clear, easy-to-use and readable LCD- bikecomputer
• 5-step PAS up to 25 km/h
• Li-ion battery 36 V/ 10.4 Ah for up to 80 km/50 miles*
• Battery removable and lockable
• About 22 kg weight including battery
• Meets the requirements of the german StVZO
• Designed in Germany, Made in EU
Subject to technical changes, errors and typographical errors.
*The range depends on the load, driving style and area of use.
Technical specifications
MECHANIC
Frame: Alloy
Rims: Alloy, black
Tires: 20“ x 2,125/ 57-406, brown side wall, reflective stripes
Shift lever: Shimano Nexus 3 with coaster brake and Revo shifter
Brakes (front/ rear): Tektro V- brakes, additional coaster brake
Headset: Semi integrated
Max. payload: 110 kg
DRIVE
Engine: AKM 100SX, front hub motor, DC 36 V/ 250 W, 50 Nm, brushless, maintenance free, IP65
Battery: 36 V/ 10,4 Ah Lithium- Ion battery w. integrated BMS and battery status indicator
Sensors: Cadence- & speedsensor
Driving modes: 5 level PAS, PAS off, push assistance
Bike computer: KD21C LC-Display, 3 buttons, backlight, IP65
Functions: SPEED, ODO, TRIP, AVG/ MAX SPEED, TRIP TIME, PAS LEVEL (0- 5), Battery, Power output, Push Assistance, Lights on/ off, Auto Power Off, Error code info
Charger: Worldwide useable switching power supply (AC 100 – 240 Volt), 42 V, 2 A
Charging time: about 4- 6 h
Range: Up to 80 km(1) / 50 miles(1)
Max. speed (PAS): max. 25 km/h
Brake cut- off sensors: Yes
LIGHTING
Lamps/ reflectors: LED- head- and rear- lights with integrated reflectors, Fully EPAC powered,
Pedals w. integrated reflectors,
Tires with circumferential reflector stripes
Brake light: Yes, integrated
FURTHER CONFIGURATION
Mudguards: Yes
Kickstand: Yes, kickstand at bb axle
Pedals: Alloy, Wellgo, foldable
Battery removable: Yes
Battery lockable: Yes
Charging if installed/ removed: Yes/ Yes
Battery indicator: Yes, integrated in battery + computer
Additional battery: Optional (10 Ah, up to 80 km (50 miles)(1) or 13 Ah, up to 100 km (60 miles)(1))
Chain protection: Yes
Luggage carrier: Yes (max. 25 kg payload)
Saddle: Selle Royal, brown
Grips Selle Royal, brown
Bell: Yes, integrated on brake lever
Sprung seat post: Yes (Promax, adjustable)
Suspension fork: No
Bottle cage: No
Carry bag: Optional
Handlebar bag: Optional
SIZE / WEIGHT
Size (unfolded): About 1600 x 160 x 1100 mm (L x B x H, w/o pedals/ handlebar), About 1600 x 610 x 1100 mm (L x B x H)
Size (folded): About 800 x 430 x 700 mm (L x B x H)
Wheel size: 24“ x 2,125
Handlebar height: 940 – 1060 mm
Handlebar: 610 mm
Saddle height: 720 – 940 mm
Seat post: Ø 28,6 mm
Wheelbase: 1000 mm
Chassis clearance: 95 mm (till chainwheel protector)
Framesize: 424 mm
Weight incl. battery: about 22 kg
Battery weight: about 3 kg (10,4 Ah battery)
Color: Titanium- matte frame, black- matte components, brown saddle/ tires/ grips
SCOPE OF DELIVERY
Foldable E-Bike, EU charger, battery with 2 keys, User manual (DE, EN, IT, PL, CS, EL, FR, NL)
REPLACEMENT BATTERY
10,4 Ah/ 36 V: Part number 2 008 020 111 050
13 Ah/ 36 V: Part number 2 008 020 111 051
CERTIFICATIONS
EPAC DIN EN 15194:2017, CE, StVZO, UN38,3
LOGISTICAL DATA (2)
Box dimensions: about 845 x 431 x 740 mm (L x W x H)
Box weight: about 3,5 kg carton, 0,1 kg foam, 0,01 kg PVC (foil, cable ties…)
Weight total: about 25 kg
Customs tariff number: 87116010
(1) The range depends on the load, driving style and area of use
(2) Subject to modification
