ENNO

Stylish, bold and foldable.
The fat folding e-bike with a lot of riding comfort thanks to extra wide 20″ tires



approx. 32 kg weight (incl. battery)
up to 80 km* range



*The range depends on the load, driving style and area of use.

Intelligent clamping mechanism!

Equipped with an intelligent quick-release mechanism, the Blaupunkt ENNO can be easily folded and thus reduced in size by half. In just 4 steps, the folding e-bike becomes a space-saving “package”.

Strong engine!

The strong 36-volt rear-wheel motor with 55 Nm provides the perfect support, which together with the removable and powerful lithium-ion battery forms a perfect team. The motor is durable and to protect the battery, the integrated BMS (Battery Management System) always ensures an optimal energy supply

LCD bike computer!

The 5 levels of the motor are controlled via the easy-to-read LCD computer. It also provides important information such as the current battery life, information about the route, speed and much more. The engine power can also be completely deactivated.

Folding fat bike ENNO

The all-purpose bike with a lot of driving comfort thanks to extra wide 20″ tires. No matter what the surface – whether sand, snow or mud – getting off and pushing or even carrying is unnecessary with this bike. The fat tires literally float over bumps and smaller obstacles.

approx. 32 kg weight (incl. battery)

up to 80 km* range

*The range depends on the load, driving style and area of use.​​
Subject to technical changes, errors and typographical errors.

Specifications

Highlights

• Foldable Fat-Bike with extra large 20” tires
• Rear hub motor with optimized controller
• Pepplegreymatte finish
• Tektro Disc brakes front & rear
• Shimano 7 speed SIS
• Stable, foldable aluminum frame
• Easily stowed thanks to intelligent quickfolding mechanism including foldable pedals & handlebar
• Comfortable 20” x 4” tires
• LCD computer with 5-step PAS up to 25 km/h
• Li-ion battery 36 V/ 13 Ah for up to 80 km/ 50 miles*
• Battery removable and lockable
• Approx. 32 kg weight including battery
• Meets the requirements of the german StVZO
• Designed in Germany

Technical specifications

Frame: Alloy
Rims: Alloy, black
Tires: 20“x 4,00, reflective stripes
Shift lever: Shimano 7-gear SIS shifter
Brakes (front/ rear): Tektro disc brakes, mechanical
Headset: Semi integrated
Max. payload: 110 kg

DRIVE
Engine: Shengyi, rear hub motor, DC 36 V/ 250 W, 55 Nm, brushless, maintenance free, IPX5
Battery: 36 V/ 13 Ah Lithium-Ion battery w. integrated BMS and RGB-LED battery status indicator
Sensors: Cadence-& speedsensor
Driving modes: Cadence-& speedsensor
Bike computer: KD21C LC-Display, 3 buttons, backlight, IP65. Functions: SPEED, ODO, TRIP, AVG/ MAX SPEED, TRIP TIME, PAS LEVEL (0-5), Battery (6 increments), Power output, Push Assistance, Auto Power Off, Error code info
Charger: Worldwide useable switching power supply (AC 100 – 240 Volt), 42 V, 2 A
Charging time: 7,5h -> 100%, 6h -> 80%
Range: Up to 80 km (1) / 50 miles (1)
Max. speed (PAS): max. 25 km/h
Brake cut-off sensors: Yes

LIGHTING
Lamps/ reflectors: LED-head-and rear-lights with integrated reflectors, Fully EPAC powered, Pedals w. integrated reflectors,
Tires with circumferential reflector stripes
Brake light: No

FURTHER CONFIGURATION
Mudguards: Yes
Kickstand: Yes
Pedals: Yes, foldable
Battery removable: Yes
Battery lockable: Yes
Charging if installed/ removed: Yes / Yes
Battery indicator: Yes, integrated in battery (RGB-LED) + computer
Additional battery: Optional (13 Ah, up to 80 km (50 miles) (1))
Chain protection: Yes, integrated
Luggage carrier: 2 (front max. 10 kg payload, rear max. 15kg payload)
Saddle: Black
Grips: Black, screwed
Bell: Yes
Sprung seat post: No
Suspension fork: No
Bottle cage: No
Carry bag: No
Handlebar bag: Optional

SIZE / WEIGHT
Size (unfolded): About 1750 x 700 x 1100 mm (L x B x H)
Size (folded): About 1000 x 500 x 750 mm (L x B x H)
Wheel size: 20“x 4,00
Handlebar height: 1150-1280 mm
Handlebar: 700 mm
Saddle height: 780-1030 mm
Seat post: Ø 31,8 mm
Wheelbase: 1145 mm
Chassis clearance: 175 mm (till frame support)/ 300 mm (BB)
Framesize: 390 mm
Weight incl. battery: about 32 kg
Battery weight: about 3,6 kg
Color: Pepplegrey matte (RAL7032)
Scope of Delivery: Foldable E-Bike, EU-Charger, battery with 2 keys, User manual (multilingual), Toolset for assembling the bike
Replacement Battery: 13 Ah/ 36V
Certifications: EPAC DIN EN 15194:2017, CE, StVZO, UN38,3

LOGISTICAL DATA (2)
Box dimensions: about 1510 x 285 x 770 mm (L x W x H )
Box weight: about 5,5 kg carton, 0,1 kg foam, 0,01 kg PVC (foil, cable ties…)
Weight total: about 37,5 kg
Customs tariff number: 87116010

NOTE:
Pre-assembled condition! Front wheel, headset, gears, brakes, luggage carrier, lamp and small parts must be mounted, adjusted or tightened and checked! Final assembly optional.

(1) The range depends on the load, driving style and area of use
(2) Subject to modification
