Mannheim 600 DAB
The Mannheim 600 DAB combines high-quality design down to the last detail, an intuitive operating concept and a breathtaking variety of functions. It impresses with its 7 ”TFT touch display and combines first-class RDS radio reception, a built-in DAB + tuner, a wide range of entertainment and many connection options to many types of mobile media. The Mannheim 600 DAB has serial interfaces such as Bluetooth and USB that allow you to comfortably play your music collection. But no matter what you’re looking for, the Mannheim 600 DAB will have a good answer for you.
Apple CarPlay and Android Auto
APPLE CARPLAY
Use your Apple iPhone® with your Mannheim 600 DAB easily and safely in the car. With Apple CarPlay, iPhone users can navigate safely and intuitively, make calls, play music and retrieve messages – simply via voice control or the touchscreen of your Mannheim 600 DAB.
ANDROID AUTO
Another connectivity feature of the Mannheim 600 DAB. Thanks to the intuitive user interface, powerful voice control and built-in Android Auto controls, distractions while driving are minimized, so you can concentrate on the traffic.
The best entertainment even without a smartphone
The best entertainment even without a smartphone
ANALOG TUNER
The CODEM IV tuner concept used in the Mannheim 600 DAB is a high-end reception concept developed by Blaupunkt. If the reception conditions change, it is important to keep the result constant. Blaupunkt has a special solution for this task: CODEM IV. Reception has been decisively improved through even better selectivity, even clearer channel separation, further freedom from distortion and other special solutions. With the high-end tuner of the CODEM IV generation from Blaupunkt, no compromises are made in terms of radio reception and RDS behavior . Once you have experienced it, even with the most difficult reception conditions, you will never want to be without it.
DIGITAL RADIO
Enjoy crystal clear, digital radio with the built-in DAB + tuner. The enjoyment begins with the selection of the programs. Be it browsing through the available ensembles and their program structure, or simply choosing from an alphabetical list of all programs.
MEDIA PLAYER
The constant use of digital, mobile data and media has become completely natural. Inevitably, it is an absolute duty of modern end devices to support them. But the range of supported media and formats alone makes the big difference. The Mannheim 600 DAB does not accept any compromises. Many audio, video and image formats are supported. There are virtually no limits to the wealth of files on the respective medium. So many tracks only make sense if the selection is easy enough. Enjoy how playfully this works with the Mannheim 600 DAB.
More features
BLUETOOTH TELEPHONIE
Once the phone book of your smartphone has been synchronized with the Mannheim 600 DAB, nothing stands in the way of comfortable communication while driving and via the audio system. For the best voice quality, the integrated or an external microphone is available for the perfect installation position.
REAR VIEW CAMERA
Parking can be a precision job. The Mannheim 600 DAB has a camera input. So you always have an overview and nothing should go wrong.
SOUND TUNING
The parametric 8-band equalizer for individual sound optimization in the vehicle can be easily and precisely set via the graphic interface of the Mannheim 600 DAB. If “playing with the frequencies” is not your thing, there is a whole range of preset sound profiles available. Depending on your personal taste, from pop, rock, electro, jazz to classical music.
SETTINGS
A breathtaking variety of functions does not mean complicated controls. All menus are consistently simple and clearly arranged, attractively designed and, above all, easy to use.
PERMANENT MEMORY
Thanks to the integrated permanent memory, the Mannheim 600 DAB saves the user settings and the preset stations if the main power supply fails.
STEERING WHEEL CONTROL
If your vehicle is equipped with a remote control on the steering wheel, you can use it together with the Blaupunkt Mannheim 600 DAB via the SWC (steering wheel control). Thanks to the SWC function, the steering wheel remote control takes over the most important functions such as volume, mute or Bluetooth of the radio.
COMPARISON OF 700, 690, 600 SERIES
Especificaciones
Highlights
Analog- / Digitalradio
FM, AM, DAB, DAB+ Tuner with PS, AF, REG, RT, CT, TA, DLS
Mediaplayer
USB, AV, Bluetooth
MP3, FLAC, OGG, WMA, WAV, MKV, AVI Support
Reverse Camera Input
Apple Car Play
Navigation, Internet radio, Music player, Apps,
Voice assistant
Android Auto
Navigation, Internet radio, Music player, Apps,
Voice assistant
Bluetooth
Phonebook access, Caller lists access,
Audio streaming with ID3 support
Sound
Digital DSP
8- Band Equalizer + Sound Presets
4-Kanal Preamplifier output + Sub-Out
4 x 45 Watts
General
High Resolution VGA TFT Display
DIM- Function
Direct access to all audio sources
Permanent memory
Steering wheel control input (SWC)
Short body, easy installation
Technical specifications
SYSTEM
User Interface: Blaupunkt graphic user interface
Permanent memory: Yes (user settings, presets etc.)
DISPLAY
Technology: LED backlight TFT
Screen size: 7″
Resolution: 1024 x 600 Pixels
Touchscreen: Yes
Display switch off: Yes
Uhr / Datumanzeige: Yes
Clock / Date display: 24 / 12 hours
Radio system languages: English, German, French, Italian, Dutch, Swedish, Polish, Portuguese, Czech
ANALOG RADIO
Type of Tuners: High-end CODEM IV
World-Tuner (switchable): No
Wave bands: FM, AM
Radio Data System (RDS): AF, PS, TA, TP, REG
Travelstore: No
Band Scan / Preset Scan: No / Yes
Search via frequency: Yes
Select via frequency scale: Yes
Station memory (presets): 18 FM / 12 AM
Frequency response (Hz) -3dB: 60 – 15.000
DIGITAL RADIO
DAB+ built-in: Yes
DAB Band III / L-band: Yes / No
Service update: Yes
Manual ensemble search: No
Station memory: 18
Ensemble browsing: No
Station browsing: Yes
Band Scan / Preset Scan: Yes / No
Service link DAB-FM: No
Radio Text: Yes
Programme Typ (PTY): No
DLS (Dynamic Label Segment): Yes
Slideshow: Yes
SMARTPHONE CONNECTIVITY
Apple CarPlay: Yes (via USB)
Android Auto: Yes (via USB)
DATA CARRIER
USB-removable storage: USB (up to 32GB)
Formatting MSD: FAT / FAT 32
MEDIA PLAYER
Video playback file formats: AVI, Mkv, DivX®
Picture playback formats: JPEG, JPG
Audio playback formats USB: MP3, WMA, FLAC, WAV, OGG
MP3 Title display: ID3-Tag (Version 1 und 2), file/folder names
Album art display: Yes
Mix: Yes (all, folder)
Repeat: Yes (all, folder, title)
Fast forward / fast rewind: Yes (via progress bar)
Number of files on MSD: up to ~ 20.000 files, depending on folder/file structure
BLUETOOTH
Supported version: Bluetooth 5.0
Supported profiles: HFP, PBAP, A2DP, AVRCP, HSP
Pairing (number of devices): 6
Hands-free calling: Yes
Voice dial: No
Key functions: accept / hang up / reject call
Phone book access: Yes (up to 1.000 entries by phone)
History call lists: Yes
Auto synchronisation: Yes
Auto connect / Auto answer: Yes / Yes
2nd call handling: No
Microphones: Built-in + external
EQUALIZER
Number of bands: 8
Model: Parametric
Type: Digital
Frequency ranges: 62 Hz/ 125 Hz/ 200 Hz/ 500 Hz/ 1.25k/ 5k/ 8k/ 12.5k
Subwoofer switchable: Yes
Subwoofer crossover freq.: 80 Hz / 120 Hz / 160 Hz
Subwoofer gain: Yes
Sound presets: Yes
Balance / Fader: Yes / Yes
AMPLIFIER
Number of channels: 4
Max. power: 4 x 45 Watt
INPUTS
Antenna: 2 (Radio- DIN, DAB -SMB)
DAB: built-in
DVB-T: No
SiriusXM: No
USB: Rear USB (Standard A-Type)
Memory cards: No
HDMI: No
Audio / Video (analogue): AV-In 1: Rear A/V (3.5 mm jack, 0,5V)
Rear view camera: Yes
Reverse gear: Yes
Handbrake: Yes
External hand-free micro: Yes (3.5 mm jack, rear)
Steering wheel remote control: Yes (SWC, rear, analogue, 3.5 mm jack, programmable via menu)
Power supply: 12 V (ISO)
OUTPUTS
4-channel preamp out: yes (RCA, 2V)
Subwoofer: yes (RCA)
Audio channels: 4
GENERAL
Installation: 2-DIN slot
Operating voltage: 10,5 – 16 V
Current consumption: In operation: < 10 A
Front Panel: Fix
Gewicht: ca. 1,03 Kg
Einbauabmessungen: 95,55 x 178 x 100 mm (T x B x H)
Colour: Black
ACCESSORIES INCLUDED IN DELIVERY
User manual included: Yes
IR remote control: Yes
DAB+ antenna: No
External hands-free micro: Yes
Mounting frame: Yes
Mounting material: Yes
Connector cable sets: Yes
