AUDIO SAMPLING
Noise-free signal transfer
CD 16bit / 44.1kHz
High-resolution Audio 24bit/96kHz
Specifications
MPA 14120 H Specifications
Amplifier
- Channel : 4
- PCB Layer : 2
- Max Output Power @ 4 Ohms : 250W x 4
- RMS Power @ 4 Ohms : 130W x 4
- RMS Power @ 2 Ohms : 180W x 4
- Max Power @ 4 Ohms Bridge : 350W x 2
- Signal-To-Noise Ratio : ≥105dB
- Gain Adjust : 300mV-8V
- Total Harmonic Distortion : <0.1%
- Damping Factor : >88
Power
- Voltage Supply : 10V-14.4V
- Idling Current : 0.5A
- Fuse : 40A x 2
Feature
- Class AB Amplifier
- Max. Output Power : 1,000W
- Frequency Response : 10Hz-40kHz
- Dimension (W x H x D) : 460 x 395 x 305mm
- Weight : 19.1kg
MPA 14120 H Accessories
- 2 x Mounting Brackets
- 4 x Screws (4 x 20mm)
- 4 x Screws (3 x 6mm)
