Clarity Behind You, Confidence Ahead.
Effortlessly discreet. Impressively sharp. The RC 1.2 delivers wide-angle, high-resolution reversing visuals—designed to keep you moving safely and smoothly.
Viewing Angle
The Blaupunkt RC1.2 can project visuals at 170° horizontal ultra wide angle of view, reducing blind spots for drivers. Without having to look in any direction, you can easily reverse park your vehicle.
Distinct Night View
Have you ever had difficulty reverse parking your car in a dark area? With 4-layer Lens Blaupunkt’s RC1.2 Reverse Camera can project images even in dim lighting.
Water Resistant
No weather can affect the performance of Blaupunkt RC1.2, even during heavy rain. The reverse camera has an IP 68 water-resistant rating to protect it from water damage.
Specifications
RC 1.2 Specifications
- Image Sensor : CMOS
- TV System : NTSC
- Effective Pixel : 652 (H) x 492 (V)
- Image Resolution : 751TVL
- Frame Frequency : 25fps
- Scanning System : 525 lines, 60 fields/sec
- Sync System : Internal
- Signal Noise ratio : >52dB
- Video Signal : 1.0Vp-p at 75ohm
- Exposure Control : Automatic
- Gain Control : Automatic
- Scope of Electronic Shutter : 1/60~1/100000sec
- White Balance : Auto (2500K~9500K)
- Illumination Min. : 0.1 Lux/F
- Character of Image : Mirror horizontal
- Operating Voltage : DC12V (DC9-12V)
- Operating Current : 160mA-180mA
- Operating Temperature : -20~60°C
- Storage Temperature : -20~60°C
- Environment Temperature : 90% RH
- Viewing Angle : 170° (D), 140° (H), 105° (V)
- Water-resistant : IP68
- Connector Type : RCA/DC
- Lens : 4-layer Lens
