FIETE 500
With the new design bike Fiete 500, Blaupunkt is offering an electric folding bike that will be a real eye-catcher on the road with its sporty look. The sturdy magnesium frame can be folded up in no time. This is ensured by the intelligent quick-release folding mechanism with magnetic lock. With its small dimensions, the bike can be easily stowed in the car, mobile home or on the boat.
Intelligent clamping mechanism!
Equipped with an intelligent clamping mechanism, the Blaupunkt Fiete 500 can be folded up very easily and thus reduced in size by half. In just 4 steps, the folding e-bike becomes a handly “package”. The low weight of approx. 21 kg also ensures that it can be easily and comfortably on the bus and train.
Power engine!
The powerful 36-volt rear-wheel hub motor with 50 Nm offers perfect support, wich, together with the integrated and powerful lithium-ion battery, forms a perfect team. The motor is durable and maintenancefree and to protect the battery, the integrated BMS (Battery Management System) always ensures an optimal supply.
LCD bike computer!
The 3 levels of the motor are controlled via the easy-to-read LCD computer. It also provides important information such as, the current battery life, information about the route, speed and much more. The engine power can also be completely deactivated.
Specifications
Highlights
- New 20″ design bike in cosmos-blue/black
- Stable, foldable magnesiumframe
- Easily stowable thanks to intelligent quick release mechanism incl. foldable pedals & handlebar
- Magnet-lock for secure folding
- Transportation wheel
- Tektro disc-brakes
- 6 gear Shimano SIS derailleur
- Comfortable 2.125 tires with puncture protection
- LCD-computer with 3-step PAS up to 25 km/h
- Li-Ion battery 36 V / 9,6 Ah with short charge time
- Battery removable and lockable
- Range up to 70 km/45 miles*
- Only about 21 kg weight (with battery)
- Meets the requierments of StVZO
*The range depends on the load, driving style and area of use.
Subject to modification.
Technical specifications
Mechanic
| Frame | Magnesium alloy |
| Rims | Magnesium, black powdered |
| Tires | 20″ x 2.125 |
| Shift lever | Shimano 6 gear SIS derailleur (44T/14T-28T) |
| Brakes (front/rear) | Tektro disc brakes, mechanical, 160 mm |
| Headset | Semi integrated |
| Max. payload | 120 kg |
Drive
| Engine | Rear hub motor, DC 36 V / 250 Nm, brushless, maintenance free |
| Battery | 36 V / 9,6 Ah LG-Lithium-Ion battery with integrated BMS (Battery Management System) |
| Controller | 36 V / 15 A DC |
| Sensors | Cadence- and speed sensor |
| Driving modes | 3 level PAS / PAS off |
| Bike computer | LC-Display with 3 function keys, backlight |
| Functions bike computer | Speed, ODO, TRIP, TIME, PAS LEVEL, battery, lights, auto-power-off, error display |
| Charger | Switching power supply (AC 100 – 240 Volt), 42 V, 2 A |
| Charging time | about 4 – 6 h |
| Range | up to 70 km/45 miles* |
| Max. speed (PAS) | max. 25 km/h |
Lighting
| Lamps/reflectors | LED-headlight with reflector, EPAC powered rechargeable USB LED-battery rear light at saddle stem, Z-reflector, pedals with integrated reflectors |
Further configuration
| Mudguards | Yes, included accessories |
| Kickstand | Yes, left sided at rear axle |
| Pedals | Foldable |
| Battery removable | Yes |
| Battery lockable | Yes |
| Charging if installed/removable | Yes/Yes |
| Battery indicator | Yes, computer display |
| Additional battery | Optional |
| Chain protection | Yes, integrated |
| Luggage carrier | No |
| Bell | Yes, integrated on brake lever |
| Sprung seat post | No |
| Suspension fork | No |
| Carry bag | Optional |
| Handlebar bag | Optional |
Size/Weight
| Size (unfolded) (LxBxH) | About 1530 x 570 x 1080 mm |
| Size (folded) (LxBxH) | About 850 x 500 x 600 mm |
| Wheel size | 20″ x 2.125 |
| Handlebar height | 1040 mm |
| Handlebar | 570 mm |
| Saddle height | 870 – 930 mm |
| Seat post | Ø 31,6 mm |
| Wheelbase | 1010 mm |
| Chassis clearance | 200 mm (till transport wheel) |
| Frame size | 600 mm |
| Weight (incl. battery) | About 21 kg |
| Battery weight | About 2 kg |
| Color | Cosmos-blue/black |
Scope of delivery
| 1 x Pedelec Fiete 500 |
| 1 x Charger |
| 1 x rechargeable battery tail light (with micro-USB cable, power adaptor not included) |
| 2 Mudguards |
| 1 x Battery with 2 keys |
| User manual (DE, EN, IT, PL, CS, DA, EL, FR, NL, SV) |
*The range depends on the load, driving style and area of use.
Subject to modification.
