20 inch e-folding bike at the highest level.
Extremely stable magnesium frame with an unmistakably cool design. The sporty bike with practical quick release mechanism.
Intelligent clamping mechanism!
Equipped with an intelligent clamping mechanism, the Blaupunkt HENRI® can be easily folded and thus reduced in size by half. In just 4 steps, the folding e-bike becomes a handy and easy-to-stow “package”. The low weight of approx. 21 kg also makes it easy and comfortable to take with you on the bus and train.
The strong 36 volt rear wheel hub motor with 50 Nm provides the perfect support, which together with the integrated and powerful lithium-ion battery forms a perfect team. The motor is durable and maintenance-free and to protect the battery, the integrated BMS (Battery Management System) always ensures an optimal energy supply.
LCD bike computer!
The 3 levels of the motor are controlled via the easy-to-read LCD computer. It also provides important information such as the current battery life, information about the route, speed and much more. The engine power can also be completely deactivated.
Folding eBike HENRI®
20 inch e-folding bike at the highest level.
Extremely stable magnesium frame with an unmistakably cool design. The sporty bike with a practical quick release mechanism.
approx. 21 kg weight (incl. battery)
up to 70 km* range
*The range depends on the load, driving style and area of use.
• Blaupunkt 20“ design bike in color agate grey/ black
• Stable, foldable Magnesiumframe
• Easily stowable thanks to intelligent quick release mechanism incl. foldable pedals & handlebar
• Magnetlock for secure folding
• Transportation wheel
• Tektro disc-brakes
• 6 gear Shimano SIS derailleur
• Comfortable 2.125 tires
• LCD-computer with 3- step PAS up to 25 km/h
• Li-Ion battery 36 V/ 10,5 Ah with short charge time
• Battery removable/ lockable
• Range up to 70 km/ 45 miles*
• Only about 21 kg weight with battery
• Meets the requirements of german StVZO
• Designed in Germany, Made in EU
*The range with one battery charge depends on many factors, such as: Support level used, driving speed, physical fitness and personal performance of the driver, shifting behavior of the driver (if gearshift is available), road conditions, wind conditions, driver’s seating position, system weight, temperature.
Frame: Magnesium alloy
Rims: Magnesium, black powdered
Tires: 20“x 2.125
Shift lever: Shimano 6- gear SIS derailleur (44T / 14T-28T )
Brakes (front/ rear): Tektro disc brakes, mechanical, 160 mm
Headset: Semi integrated
Max. payload: 120 kg
Engine: Rear hub motor Xiongda XD-20GS, DC 36 V/ 250 W, 50 Nm, IP54, brushless, maintenance free
Battery: 36 V/ 10,5 Ah LG- Lithium- Ion battery w. integrated BMS
Controller: 36 V/ 15 A DC
Sensors: Cadence- & speed sensor
Driving modes: 3 level PAS/ PAS off
Bike computer: LC- Display wit 3 function keys, backlight. Functions: Speed, ODO, TRIP, TIME, PAS LEVEL, battery, lights, auto- power- off, error display
Charger: Switching power supply (AC 100 – 240 Volt), 42 V, 2 ACharging time: about 4- 6 h
Range: Up to 70 km/ 45 miles (1)
Max. speed (PAS): max. 25 km/h
Lamps/ reflectors: LED- headlight with reflector, EPAC powered Rechargeable USB LED- battery rear light at saddle stem Z- reflector, Pedals w. integrated reflectors
Tires with circumferential reflector stripes
Mudguards: Yes, included accessories
Kickstand: Yes, left sided at rear axle’
Battery removable: Yes
Battery lockable: Yes
Charging if installed/ removed: Yes / Yes
Battery indicator: Yes, computer display
Additional battery: Optional
Chain protection: Yes, integrated
Luggage carrier: No
Bell: Yes, integrated on brake lever
Sprung seat post: No
Suspension fork: No
Carry bag: Optional
Handlebar bag: Optional
SIZE / WEIGHT
Size (unfolded): About 1530 x 570 x 1080 mm (L x B x H)
Size (folded): About 850 x 500 x 600 mm (L x B x H)
Wheel size: 20“x 2,125
Handlebar height: 1040 mm
Handlebar: 570 mm
Saddle height: 870- 930 mm
Seat post: Ø 31.6 mm, 300 mm (optional 400 mm)
Wheelbase: 1010 mm
Chassis clearance: 200 mm (till transport wheel)
Framezize: 600 mm
Weight incl. battery: about 21 kg
Battery weight: about 1.5 kg
Color: Agate Grey (RAL 7038)/ black
Scope of Delivery: E-Bike, Charger, Rechargeable battery tail light (with micro- USB cable, power adaptor not included), Mudguards, Battery with 2 keys, User manual (DE, EN, IT, PL, CS, DA, EL, FR, NL, SV)
Replacement Battery: Partnumber 2 008 020 111 069
Certifications: EPAC DIN EN 15194:2017, CE, StVZO, UN38,3, IPX4
LOGISTICAL DATA (2)
Box dimensions: about 850 x 430 x 640 mm (L x W x H)
Box weight: about 4 kg carton, 0,1 kg foam 0,01 kg PVC (foil, cable ties…)
Weight total: about 26.5 kg
Customs tariff number: 87116010
*The range depends on the load, driving style and area of use
(2) Subject to modification
