Bremen SQR 46 DAB

Back to the Future!

The newly launched cult car radio “Bremen SQR 46 DAB” with many new features!

Over the years, some models have become true cult objects. This also applies to the legendary Blaupunkt “Bremen SQR 46” from 1986. We are now presenting the reinterpretation of the popular 1-DIN car radio and combining the USPs of the 80s model with new technologies and functions. The result is the Blaupunkt “Bremen SQR 46 DAB”.

Its operating concept, the simple design and the crystal-clear reception made a significant contribution to the popularity of the original Bremen car radio. For the new edition, we took over the styling of the original model, but at the same time gave the radio modern Variocolor lighting for the buttons and the display. Thanks to the Blaupunkt Codem FM RDS tuner and DAB+ digital tuner, first-class reception remains a strength of the new Youngtimer car radio. The numerous serial interfaces are new, including two USB ports, an auxiliary connection and an SDHC slot – audio streaming via Bluetooth is also not a dream of the future for the returning legend. This radio is also “Made for iPhone/iPod” and guarantees a corresponding compatibility. All settings are saved permanently even if the battery is disconnected. A DAB+ windshield antenna is also included – so the entertainer has arrived in the present.

The new “Bremen SQR 46 DAB” has a short installation depth – ideal for youngtimers with shortened installation shafts. But not only the car radio itself takes the user on a journey through time, the packaging of the device was also elaborately designed and modeled on the original.



High-End CODEM IV High-End World-Tuner
FM (RDS), AM Tuner
DAB+ Tuner built-in

Data Carrier
USB, SD, SDHC (up to 32 GB)

Media player
Audio from USB/SDHC
Audio formats MP3, WMA

Bluetooth module built-in (HFP, PBAP, A2DP, SPP, AVRCP)
Phone book access
Built-in + external microphone
Navigation audio mix

Input / Output
1x front USB
1x rear USB
1x front Aux-In
1x front SDHC slot
Steering wheel control input (programmable)

Equalizer / Amplfier
3-band, semi-parametric equalizer
Sound presets (Rock, Pop, Classic)
4-channel preamp-out (4V)
Separate Sub-Out
4 x 50-Watt max. power

Vario Colour (RGB for display & button illumination)
Fix front panel
Permanent memory
Short mounting depth
IR remote control included in delivery
DAB+ onglas antenna included in delivery
External BT- mircophone included in delivery

Technical specifications

DAB / DAB+: yes / yes
Band III / L-Band: yes / no
Service Scan: yes
Preset stations: 15 (DAB 1,2,3)
Ensemble / Programme: yes
Comfort browsing: yes
Programme scan: yes
Service-link DAB-DAB: yes
Service-link DAB-FM: yes
Service-link DAB-DAB-FM: yes
Traffic announcement: yes (via FM RDS TA)
DLS: yes
PTY Programme: yes
Frequency response (Hz) +/- 3 dB: 20 – 20.000

Type of tuner: High-End Automotive Tuner Blaupunkt CODEM
World tuner (switchable): EU, Americas, Thailand
Wave bands: FM 1, 2, MW,
Radio Data System (RDS): Alternative Frequency (AF), Radiotext (RT), Clock Time (CT), Enhanced Other Networks (EON), Programme Service Name (PS), Program Types (PTY), Regional Programme (REG), Traffic Announcement (TA), Traffic Program (TP)
Travelstore: yes (FMT)
Band Scan / Preset Scan: yes / yes
Station memory: 25
Sensitivity: lo / dx
Interference suppression: yes
Hi-Cut: yes
Frequency response (Hz) -3 dB: 30 – 15.000

Supported version: Bluetooth 2.1 mit EDR
Supported profiles: HFP, PBAP, A2DP, AVRCP, SPP
Pairing (number of devices): 5
Pairing Code: 1234
Hands-free calling: via micro + radio speaker
Hands-free volume: variable
Microphone: built-in + external microphone
Key functions: accept / hang-up / reject call / redail
Phone book access: yes (up to 1.000 entries by phone)
Twin Connect: yes (2 simultaneously connected phones for telephony)
Navigation Audio Mix: yes (Navigation commands via A2DP)
Auto Wake-Up: yes (radio switched off / ignition on)

USB: 2x USB 2.0
Memory cards: SDHC (up to 32 GB), SD, MMC
Formatting USB / SD: FAT 32, FAT 16

Playback format: MP3, WMA
Title display: ID3-tag (version 2), file, folder
Folder- & file browsing: yes (w/o track interruption)
Multiple folder level from MSD: yes
iPod, iPhone control: yes (via USB)
Fast list browsing: yes (via second encoder)
Display modes: yes (file, folder, song, artist, album, clock, elapsed time, total time, all mode)
Display of characters: File name up to 50, tags up to 30
Variable display scrolling: yes
Mix / Repeat / Scan: yes / yes / yes
Fast media reading: yes (from USB, SDHC, SD)
Number of supported files: > 30.000 from MSD
Bitrate (kBit/s): 32 -320
Variable bitrate : yes

Number of bands / model: 3 / parametric
Bass / Treble: yes / yes (+/- 7 steps)
Balance / Fader : yes / yes (+/- 9 steps)
X-Bass: yes
Sound presets: Rock, Pop, Klassik

Number of channels: 4
Max. Power: 4 x 50 Watt
Sinus power at 14.4 V: 4 x 24 Watt (DIN 45324)

Type / Digits: 1-line / 9
Angle: Wide-view
Color: Variocolor (RGB)
Brightness: adjustable
Clock display: 24 / 12 hrs

Antenna (number of): 2 (FM ISO + DAB SMB)
USB (number of / type): 2 (front + rear / standard A-Typ)
iPod/iPhone: yes (via front + rear USB)
Memory cards: yes
Aux-In (number of, type): 1 front (3,5 mm jack)
Telephone-mute: yes
Steering wheel control: yes (analog programmable)

Loudspeaker (number of): 4
Pre-amplifier (channel): 4 (Cinch)
Pre-amplifier (voltage): 4 Volt
Variable amplifier delay time: yes
Sub-Out: yes (Cinch, var. gain/frequency)

Software Update: yes, via USB
Variable scan-time: yes
Confirmation-beep: yes (on/off)
Front panel: Fix-Panel
Panel / decor-ring color: black / black
Key illumination: Vario colour (RGB)
Permanent preset storage: yes (settings & presets)
Demo mode: yes
Weight (kg): ca. 0,85
Dimension (mm): 58 x 178 x 110 (H x W x D)
Voltage supply: 10.5 – 14.4 V
Current consumption: In operation: < 10A
10 sec. after switch off: < 3.5 mA
DAB-onglas antenna: yes (included in delivery)
IR remote control: yes (included in delivery)
External BT microphone: yes (included in delivery)
