VELOCITY POWER DSP WITH CLASS D AMPLIFIER
MPD 101280 AH
10-CH High Level Inputs | 2-CH Low Level Inputs | 12-CH High/Low Level Outputs
Specifications
MPD 101280 AH Specifications
Audio
- RMS Power : 40W x 12 at 4ohm
- Max. Output Power @ 4 Ohms (≤10% THD +N) : 80W x 12
- DSP Resolution : 32 Bit
- DSP Power : 295MHz
- Distortion (THD) : < 0.05%
- Damping Factor : 20
- Operating Voltage : 9V -16V
- Sampling Rate : 96KHz/32Bit
- Signal Converter A/D : PCM1840
- Signal Converter D/A : PCM1681
- RCA/Cinch Input Sensitivity : 6.5V
- Max. RCA/ Cinch Output: 8V
Input
- 2 x Low Level RCA Input
- 1 x Coaxial Input
- 10 x High Level Speaker Inputs
- 1 x USB input
- 1 x Optical SPDIF Input
- Impedance High Level : 4.7 ohms
- Impedance Low Level : 10k ohms
- S/N Ratio Analog-in : ≥97dB
Output
- 12 x RCA/ Cinch Output
- 12 x High Level Speaker Outputs
Feature
- Class D Amplifier
- Built-in BT for Music Playback
- Max. Output Power : 960W
- Frequency Response : 20Hz-40kHz
- Max. Current Draw : 40A
- Dimension (W x H x D) : 254 x 186.3 x 46.7mm
- Weight : 3.1 kg
