Extremely stable magnesium frame in an unmistakably cool design with a range of up to 70 km*.

20 inch e-folding bike at the highest level.
Extremely stable magnesium frame with an unmistakably cool design. The sporty bike with practical quick release mechanism.

Approx. 21 kg weight (incl. battery) up to 70 km range*

*The range depends on the load, driving style and area of use.

Intelligent clamping mechanism!

Equipped with an intelligent clamping mechanism, the Blaupunkt Fiete 500 can be easily folded and thus reduced in size by half. In just 4 steps, the folding e-bike becomes a handy “package”. The low weight of approx. 21 kg also makes it easy and comfortable to take with you on the bus and train.

Strong engine!

The strong 36-volt rear wheel hub motor with 50 Nm provides the perfect support, which together with the integrated and powerful lithium-ion battery forms a perfect team. The motor is durable and maintenance-free and to protect the battery, the integrated BMS (Battery Management System) always ensures an optimal energy supply.

LCD bike computer!

The 3 levels of the motor are controlled via the easy-to-read LCD computer. It also provides important information such as the current battery life, information about the route, speed and much more. The engine power can also be completely deactivated.



• Blaupunkt 20“ design bike in color cosmos- blue/ black
• Stable, foldable Magnesiumframe
• Easily stowable thanks to intelligent quick release mechanism incl. Foldable pedals & handlebar
• Magnet- lock for secure folding
• Transportation wheel
• Tektro disc- brakes
• 6 gear Shimano SIS derailleur
• Comfortable 2.125 tires
• LCD- computer with 3- step PAS up to 25 km/h
• Li- Ion battery 36 V/ 9,6 Ah with short charge time
• Battery removable/ lockable
• Range up to 70 km/ 45 miles*
• Only about 21 kg weight with battery
• Meets the requirements of german StVZO
• Designed in Germany, Made in EU

Technical specifications

Frame: Magnesium alloy
Rims: Magnesium, black powdered
Tires: 20“x 2.125
Shift lever: Shimano 6- gear SIS derailleur (44T / 14T-28T )
Brakes (front/ rear): Tektro disc brakes, mechanical, 160 mm
Headset: Semi integrated
Max. payload: 120 kg

Engine: Rear hub motor Xiongda XD-20GS, DC 36 V/ 250 W, 50 Nm, IP54, brushless, maintenance free
Battery: 36 V/ 9,6 Ah LG- Lithium- Ion battery w. integrated BMS
Controller: 36 V/ 15 A DC
Sensors: Cadence- & speed sensor
Driving modes: 3 level PAS/ PAS off
Bike computer: LC- Display wit 3 function keys, backlight. Functions: Speed, ODO, TRIP, TIME, PAS LEVEL, battery, lights, auto- power- off, error display
Charger: Switching power supply (AC 100 – 240 Volt), 42 V, 2 A
Charging time: about 4- 6 h
Range: Up to 70 km/ 45 miles (1)
Max. speed (PAS): max. 25 km/h

Lamps/ reflectors: LED- headlight with reflector, EPAC powered Rechargeable USB LED- battery rear light at saddle stem Z- reflector, Pedals w. integrated reflectors Tires with circumferential reflector stripes
Brake light: No

Mudguards: Yes, included accessories
Kickstand: Yes, left sided at rear axle
Pedals: Foldable
Battery removable: Yes
Battery lockable: Yes
Charging if installed/ removed: Yes / Yes
Battery indicator: Yes, computer display: Optional
Additional battery: Optional
Chain protection: Yes, integrated
Luggage carrier: No
Bell: Yes, integrated on brake lever
Sprung seat post: No
Suspension fork: No
Carry bag Optional
Handlebar bag Optional

Size (unfolded): About 1530 x 570 x 1080 mm (L x B x H)
Size (folded): About 850 x 500 x 600 mm (L x B x H)
Wheel size: 20“x 2,125
Handlebar height: 1040 mm
Handlebar: 570 mm
Saddle height: 870- 930 mm
Seat post: Ø 31,6 mm, 300 mm (optional 400 mm)
Wheelbase: 1010 mm
Chassis clearance: 200 mm (till transport wheel)
Framezize: 600 mm
Weight incl. battery: about 21 kg
Battery weight: about 1,5 kg
Color: Cosmos-blue/ black
Scope of Delivery: E-Bike, Charger, Rechargeable battery tail light (with micro- USB cable, power
adaptor not included), Mudguards, Battery with 2 keys, User manual (DE, EN, IT, PL, CS, DA, EL, FR, NL, SV)
Replacement Battery: 9,6 Ah/ 36 V: Part number 2 008 020 111 069
Certifications: EPAC DIN EN 15194:2017, CE, StVZO, UN38,3, IPX4

Box dimensions: about 850 x 430 x 640 mm (L x W x H)
Box weight: about 4 kg carton, 0,1 kg foam 0,01 kg PVC (foil, cable ties…)
Weight total: about 26,5 kg
Customs tariff number: 87116010

*The range depends on the load, driving style and area of use
(2) Subject to modification
